Home Theatre Digital Amplifier Wireless/USB/SD Card/FM/Aux Audio Power SA

Power Power Switch Turn ON/OFF unit power

Volume Main Channel Volume Adjust Knob

Selector Audio Input Selector

Input Audio Input Selector Turn A/B Unit Input

HIGH Main Channel Treble Adjust Knob

LOW Main Channel Bass Adjust Knob

BAL Main Channel Balance Adjust Knob

VOL Main Channel Volume Adjust Knob

MIC1 Microphone Input Jack1
MIC2 Microphone Input Jack2
MIC1 VOL Microphone Channel 1 Volume Adjust Knob
MIC2-VOL Microphone Channel 2 Volume Adjust Knob
M.HIGH Microphone Treble Adjust Knob
M.LOW Microphone Bass Adjust Knob
ECHO REP Microphone Echo Adjust Knob
DELAY Microphone Delay Adjust Knob

SD Mp3 SD Input Jack
USB Mp3 USB Input Jack
NEXT Mp3 Audio Next
PREV Mp3 Audio Prev
PALY Mp3 Audio Paly
MODE Input Mode Selector

OPERATIONG INSTRUCTIONS

Pressed POWER Switch Power on The Unit Into Working State

Volume Adjust
Rotate The VOLUME Control At Front Panel

Input Selection
Press The One of A B Selector Then Selector The Audio Input Signal

TONE and Balance of The Main Channel
Rotate The BASS Knob To Adjust The BAS S Output of The Main Channel Rotate The TREBLE Knob To Adjusted TREBLE Output of The Main Channel Rotate The BALANCE Knob To Adjust The BALANCE Output of The Main Channel

Microphone Volume Adjust
Rotate The MIC 1/MIC2 VOL Knob To Adjust The Volume Of Microphone

Microphone Tone Adjust
Rotate The M Tone Knob To Adjust The Tone of Microphone

Echo Adjust Rotate The ECHO Knob To Adjust The Deepness of Microphone Echo and Delay Effect

Mp3 Audio Input
Insert

What’s in the box
1 X Home Theatre Digital Amplifier Wireless/USB/SD Card/FM/Aux Audio Power SA
